19-7
19 TOP FIELD MODE
7 Enter a reflector height.
Enter
reflector
height
8 Set with {ENT} key.
{ENT}
9 Select the coordinate point of a collimate point
with {F1} or {F2} (Arrow) key, or enter the
coordinate point directly. *1)
Enter/
Select PT#
10 Set with {ENT} key.
{ENT}
11 Collimate prism and press {F1} (MSR) key.
Begin measurement.
{F1}
12 When the prism measurement is completed,
perform measurement for the next collimate point.
 Follow the same procedure.
After the prism is measured the set number of
times, the occupied point coordinates will be
calculated and the standard deviation will be
displayed.
13 Press {F1} (OK).
The screen for inputting the coordinate point of an
occupied point and its description will be
displayed.
{F1}
14 Enter the coordinate point of an occupied point
and its description.
Enter PT#,
Enter
DESC
ENTER TARGET HT
HT OF ROD
=1.500_ m
CLR
ENTER TARGET PT# 1/2
PT#: [_ ]
↑ ↓ ALP CLR
ENTER TARGET PT# 1/2
PT#: [PT-01_ ]
↑ ↓ ALP CLR
MEAS POINT 1/2
PT#: [PT-01 ]
HD: m
MSR CHK HR
MEAS POINT 1/2
PT#: [PT-01 ]
HD* <<< m
>Measuring...
ENTER TARGET PT# 2/2
PT#: [PT-01_ ]
↑ ↓ ALP CLR
MEAS POINT 2/2
PT#: [PT-01 ]
HD* <<< m
>Measuring...
dN: 0000.00 mm
dE: 0000.00 mm
dZ: 0000.00 mm
OK NO
ENTER NEW POINT:
PT#: [_ ]
DESC: [ ]
ALP CLR
ENTER NEW POINT:
PT#: [OCC ]
DESC: [POINT_ ]
ALP CLR
