19 TOP FIELD MODE
 Checking collimate point coordinates during prism collimation
 Checking prism height during prism collimation
 Checking occupied point coordinates during occupied point/backsight setting
To set backsight
After completing the occupied point setting, the display for backsight setting will be displayed.
15 Set with {ENT} key.
{ENT}
16 When you press {F1} (OK), an occupied point and
backsight will be set and the procedure will be
completed.
 The backsight is set up based on the previously
collimated prism position. Therefore, always press
{OK} under the condition in which the previous
prism backsight collimated.
{F1}
Operating procedure Operation Display
1 To check the collimate point coordinates during
prism collimation, select {F2} (CHK) key.
{F2}
Operating procedure Operation Display
1 To check the prism height during prism collimation,
select {F3} (HR) key.
{F3}
Operating procedure Operation Display
1 To check the occupied point coordinates during
occupied point/backsight setting, select {F2}
(NEZ) key.
{F2}
POINT X SET!
ORIENTATION SET!
OK NEZ
1.INST SETUP
2.LAYOUT
3.TOPO
[1] [2] [3]
MEAS POINT 1/2
PT#: [PT-01 ]
MSR CHK HR
N [ 10.000 ]
E [ 20.000 ]
Z [ 0.000 ]
ENTER
MEAS POINT 1/2
PT#: [PT-01 ]
MSR CHK HR
ENTER TARGET HT
HT OF ROD
=1.500_ m
CLR
POINT X SET!
ORIENTATION SET!
OK NEZ
N [ 0.000 ]
E [ 0.000 ]
Z [ 0.000 ]
ENTER
