1-5
1 NOMENCLATURE AND FUNCTIONS
Angle measurement
Distance measurement mode
Coordinate measurement mode
Page
Soft
key
Display
mark
Function
1
{F1} 0SET Angle of Horizontal is set to 0°00'00"
{F2} HOLD Hold the horizontal angle.
{F3} HSET Sets a required horizontal angle by entering numerals.
{F4} P1
↓ The function of soft keys is shown on next page (P2).
2
{F1} TILT
Setting Tilt Correction
If ON, the display shows tilt correction value.
{F2} REP Repetition angle measurement mode
{F3} V% Vertical angle percent grade(%) mode
{F4} P2
↓ The function of soft keys is shown on next page (P3).
3
{F1} H-BZ Sets the buzzer sound for every horizontal angle 90°.
{F2} R/L Switches R/L rotation of horizontal angle.
{F3} CMPS Switches the COMPASS ON/OFF of vertical angle.
{F4} P3
↓ The function of soft keys is shown on next page (P1).
1
{F1} MEAS Start measuring
{F2} MODE Sets a measuring mode, Fine/Coarse/Tracking.
{F3} NP/P Switches non-prism mode, prism mode or sheet mode.
{F4} P1
↓ The function of soft keys is shown on next page (P2).
2
{F1} OFSET Select Off-set measurement mode.
{F2} S.O Select stake out measurement mode.
{F3} S/A Select set audio mode.
{F4} P2
↓ The function of soft keys is shown on next page (P3).
3
{F2} m/f/i Switches meter, feet or feet and inch unit.
{F4} P3
↓ The function of soft keys is shown on next page (P1).
1
{F1} MEAS Start measuring.
{F2} MODE Sets a measuring mode, Fine/Coarse/Tracking.
{F3} NP/P Switches non-prism mode, prism mode or sheet mode.
{F4} P1
↓ The function of soft keys is shown on next page (P2).
2
{F1} R.HT Sets a prism height by input values.
{F2} INSHT Sets an instrument height by input values.
{F3} OCC Sets an instrument coordinate point by input values.
{F4} P2
↓ The function of soft keys is shown on next page (P3).
3
{F1} OFSET Select Off-set measurement mode.
{F2} m/f/i Switches meter, feet or feet and inch unit.
{F3} S/A Select set audio mode.
{F4} P3
↓ The function of soft keys is shown on next page (P1).
