4-8
4 DISTANCE MEASUREMENT
The horizontal distance from the instrument to the
prism will be measured.
5 Collimate point A
0
using the horizontal motion
clamp and horizontal tangent screw.
Collimate
A
0
6 Show the relative elevation of point A
0
.
{}
7 Show the slope distance of point A
0
.
 Each time pressing the {} key, horizontal
distance, relative elevation and slope distance are
shown in sequence.
{}
8 Show N coordinate of point A
0
or A
1
.
 Each time pressing {} key, N,E and Z
coordinate are shown in sequence.
{}
 To return to procedure
4, press the {F1} (NEXT) key.
 To return to the previous mode, press the {ESC} key.
 Press the {F3} (NP/P) key after the step
3 to change target type.
OFFSET-MEASUREMENT
HR: 110°20'30"
HD: 56.789 m
NEXT --- --- ---
OFFSET-MEASUREMENT
HR: 113°30'50"
HD: 56.789 m
NEXT --- --- ---
OFFSET-MEASUREMENT
HR: 113°20'30"
VD: 3.456 m
NEXT --- --- ---
OFFSET-MEASUREMENT
HR: 113°20'30"
SD: 56.894 m
NEXT --- --- ---
OFFSET-MEASUREMENT
HR: 113°20'30"
N : -12.345 m
NEXT --- --- ---
