6 SPECIAL MODE (Menu Mode)
2) Without prism height input
Horizontal distance (HD) between the instrument
and prism will be shown.
8 Collimate target K.
Vertical distance (VD) will be shown. *2),3)
Collimate K
*1)
Refer to Section 2.4 “How to Enter Alphanumeric Characters”.
*2) To return to procedure
5, press the {F2} (R.HT) key.
To return to procedure
6, press the {F3} (HD) key.
*3) To return to PROGRAMS Menu, press the {ESC} key.
Operating procedure Operation Display
1 After pressing the {MENU} key, press the {F4}
(P
↓ ) key to get the menu on page 2.
{MENU}
{F4}
2 Press the {F2} key.
{F2}
3 Press the {F1} (REM) key.
{F1}
4 Press the {F2} key.
{F2}
5 Collimate prism.
Collimate P
6 Press the {F1} (MEAS) key.
Measuring starts.
{F1}
Horizontal distance (HD) between the instrument
and prism will be shown.
REM-1
<STEP-2>
HD* 123.456 m
>Measuring...
REM-1
VD: 1.500 m
––– R.HT HD –––
REM-1
VD: 10.456 m
––– R.HT HD –––
MENU 2/4
F1:MEMORY MGR.
F2:PROGRAMS
F3:GRID FACTOR P
↓
PROGRAMS 1/2
F1:REM
F2:MLM
F3:Z COORD. P
↓
REM
F1:INPUT R.HT
F2:NO R.HT
REM-2
<STEP-1>
HD: m
MEAS ––– NP/P –––
REM-2
<STEP-1>
HD* [n] << m
>Measuring...
REM-2
<STEP-1>
HD* 123.456 m
>Measuring...
