6-6
6 SPECIAL MODE (Menu Mode)
5 Press the {F1} or {F2} key to select using
GRID FACTOR.
[Example:F2 : DON’T USE]
{F2}
6 Press the {F1} key.
{F1}
7 Collimate prism A, and press the {F1} (MEAS) key.
Horizontal distance (HD) between the instrument
and prism A will be shown.
Collimate A
{F1}
The prism position will be decided.
8 Collimate prism B and press the {F1} (MEAS) key.
Horizontal distance (HD) between the instrument
and prism B will be shown.
Collimate B
{F1}
The horizontal distance (dHD) and relative
elevation (dVD) between prism A and B.
9 To show slope distance (dSD), press {} key.
{}
10 To measure the distance between points A and C,
press the {F3} (HD). *1)
{F3}
11 Collimate point C (Prism C) and press the
{F1} (MEAS) key.
Horizontal distance (HD) between the instrument
and prism C will be shown.
Collimate
prism C
{F1}
MLM
F1:MLM-1(A-B, A-C)
F2:MLM-2(A-B, B-C)
MLM-1(A-B, A-C)
<STEP-1>
HD: m
MEAS R.HT NEZ NP/P
MLM-1(A-B, A-C)
<STEP-1>
HD*[n] << m
MEAS R.HT NEZ NP/P
MLM-1(A-B, A-C)
<STEP-1>
HD* 123.456 m
MEAS R.HT NEZ NP/P
MLM-1(A-B, A-C)
<STEP-2>
HD: m
MEAS R.HT NEZ NP/P
MLM-1(A-B, A-C)
<STEP-2>
HD*[n] << m
MEAS R.HT NEZ NP/P
MLM-1(A-B, A-C)
<STEP-2>
HD* 345.678 m
MEAS R.HT NEZ NP/P
MLM-1(A-B, A-C)
dHD : 123.456 m
dVD : 12.345 m
––– ––– HD –––
MLM-1(A-B, A-C)
dSD : 124.072 m
HR : 12°34'40"
––– ––– HD –––
MLM-1(A-B, A-C)
<STEP-2>
HD: m
MEAS R.HT NEZ NP/P
