6-30
6 SPECIAL MODE (Menu Mode)
 Input SPIRAL data
Operating procedure Operation Display
1 To input SPIRAL data, press the {F3} key. *1)
{F3}
2 Input RADIUS.
3 Press the {ENT} key.
4 Input LENGTH.
5 Press the {ENT} key.
6 Select TURN (direction of turn): RIGHT or LEFT.
7 Press the {ENT} key.
Input
RADIUS
{ENT}
Input
LENGTH
{ENT}
Select
{F1}
(LEFT)
or
{F2}
(RIGHT)
{ENT}
8 Select DIR (direction): IN (entrance) or OUT (exit).
9 Press the {ENT} key.
Select
{F1}
(IN)
or
{F2}
(OUT)
{ENT}
*1) SPIRAL cannot be input as the first data.
F1:LINE
F2:CURVE
F3:SPIRAL
F4:POINT
SPIRAL 03
R = 0.000 m
L : 0.000 m
--- --- [CLR] [ENT]
SPIRAL 03
R : 100.000 m
L = 0.000 m
--- --- [CLR] [ENT]
SPIRAL 03
TURN > RIGHT
DIR : IN
LEFT RIGHT --- ENTER
SPIRAL 03
TURN : LEFT
DIR > IN
IN OUT --- ENTER
<SET!>
