Topcon GR-3 User Manual

Receiver Setup
P/N 7010-0736
4-3
Figure 4-1. Install Tripod and Receiver over Control Point
To set up the Rover receiver (Figure 4-2 on page 4-4):
1. If needed, attach the quick disconnect to the bipod/range pole.
2. Attach the GR-3 receiver to the quick disconnect. Make sure the
receiver locks into place.
NOTICE
Use a bipod during post-process surveys to ensure
the antenna/receiver does not move during data
logging.
GR-3 Receiver
Horizontal Spacer
Tribrach Adapter (Precision)
Universal Tribrach
