Introduction
GR-3 Operator’s Manual
1-20
Along with the above cables, the GR-3 package with a GB-500 or
GB-1000 receiver includes the cables listed in Table 1-4. Refer to the
GB-500 Operator’s Manual or GB-1000 Operator’s Manual for
further details on the accessories that come with these receivers.
Table 1-4. GR-3 with GB-500/1000 Package Cables
Cable Description Cable Illustration
GPS antenna cable
Connects the GB-500/1000 receiver
to the antenna connector on the
PG-A1 antenna.
p/n 14-050402-01
Antenna RF cable
Connects the GB-500/1000 to an
external radio modem.
p/n 14-008109-01LF
Alligator clips cable
Connects any 12-volt DC power
source to the receiver via the SAE
cable.
p/n 14-008025-01
SAE-to-SAE extension cable
Connects SAE connectors over
longer distances.
p/n 14-008022-01
