Getting Acquainted
P/N 7010-0736
1-23
receiver can be quickly connected to/disconnected from the range
pole (Figure 1-14).
Figure 1-14. Quick Disconnect
A hand-held controller (Figure 1-15) allows the GR-3 Base and
Rover systems to be configured and monitored directly in the field.
TopSURV (field data collection software) and CE-CDU (receiver
configuration and monitoring software) can be used on Topcon
controllers to configure and manage the receiver.
Figure 1-15. Hand-held Controller Examples
The ODU-to-alligator clips cable (p/n 14-008097-01LF) connects
the charging cradle or receiver to an auxiliary battery for powering the
receiver during survey operations (Figure 1-14).
Figure 1-16. Auxiliary Power Cable – ODU-to-Alligator Clips
