Configuring a Spread Spectrum Radio Modem
P/N 7010-0736
3-7
Figure 3-2. Modem-TPS Radio Link Tab
On the Radio Link tab, set the following parameters (Table 3-2) and
click Apply
Table 3-2. Receiver Parameters for the Radio Link Tab
Parameter Base Receiver Rover Receiver
Protocol Recommend selecting FH915
for Base and Rover settings,
unless the RE-S1 (Radio
Extension System/Spread
Spectrum Repeater) is being
used. For more information,
see the RE-S1 Operator’s
Manual p/n: 7010-0780.
Rover settings must match the
Base settings
Location Select the country in which
the receiver will be used.
Operation
mode
Select Off if the radio is
turned off.
Select Receiver.
Select Transmitter.
