Topcon GR-3 User Manual

Configuring the Receiver
P/N 7010-0736
3-29
5. Select ConfigurationReceiver.
6. Click Set all parameters to defaults (Figure 3-22).
Figure 3-22. Set All Parameters to Defaults
7. Click the MINTER tab, and configure the following settings
(Table 3-9), then click Apply (Figure 3-23).
NOTICE
Click Apply after making any configuration
change; otherwise, the receiver will not register the
change.
Table 3-9. Receiver Parameters for the MINTER Tab
Parameter Base Receiver Rover Receiver
Recording
interval
Enter 15 seconds.
Elevation
mask angle
Enter 15 degrees.
File name
prefix
Enter a unique ID, such as the last 3 digits of receiver’s serial
number.
FN key mode (starts/stops data recording using the FUNCTION key)
For Static data recording,
select LED blink mode switch.
For RTK data recording,
select Occupation mode
switch.
