Configuring the Receiver
P/N 7010-0736
3-31
• GPS/GLO at one time – enable
• Antenna position – enter Lat, Lon, and Alt values using one
of the following methods:
– If known, type in the values.
– Enable Averaged, and enter the Averaged Span in
seconds, then click Apply. Click ToolsReset receiver
and wait until the specified interval (span) completes.
Examine the Base coordinates on the Base tab; they
should correspond to the coordinates obtained from the
average. Click Refresh if the coordinates are zeros.
– Click Get from receiver.
Figure 3-25. Base Configuration
10. For the Rover receiver, click the Rover tab, and set the following
parameters, then click Apply (Figure 3-26 on page 3-32).
• Positioning Mode – For post-processed surveys, select
Standalone; for RTK surveys, select RTK float or RTK fixed.
The reference geodetic coordinates specified on this
tab relate to the antenna L1 phase center.
