Machine Measurements and Configuration
15
X-52/X-72 2D Excavator Installation and Calibration Manual P/N: 1022461-01
Machine Measurements and Configuration
Taking Machine Measurements
Before taking machine measurements, note the following:
• Check the sensor’s serial numbers before installing. The last two digits of the serial number
determine the sensor CAN address, and must be unique to each machine.
For example, sensor serial number 0302 and 0402 will have the same CAN address (“02”), causing
communication errors.
• A sensor ending in 00 is considered a special CAN identifier, and will be identified as 01 in 3D-MC;
therefore; if you have a sensor with 00 and a sensor with 01, there will be some confusion in
3D-MC.
• Accurately measure and enter the machine dimensions into the 3D-MC machine builder, and write
your measurements on the lines at the side of the following screen captures.
Incorrect measurements or data entry errors have a direct affect on excavating accuracy.
Take each measurement twice to ensure accuracy.
