Topcon X-52 - GR-i3

Machine Measurements and Configuration
Taking Machine Measurements
16
X-52/X-72 2D Excavator Installation and Calibration Manual P/N: 1022461-01
GR-i3
The following two (2) screens, Excavator IMU Mounting and Boom/Body (1), are
only applicable, if using a GR-i3 with internal IMU.
For GR-i3 without internal IMU, only the Boom/Body (2) screen is applicable.
IMU Sensor
(GR-i3 with Internal
IMU Only)
Boom/Body (1)
ĞŶƚĞƌŽĨZŽƚĂƟŽŶ
(GR-i3 with Internal
IMU Only)
Boom/Body (2)
Pivot Height
