Setup Verification
42
X-52/X-72 2D Excavator Installation and Calibration Manual P/N: 1022461-01
Setup Verification
Performing a full system test verifies the accuracy of the excavator systems at various machine positions.
String Line Verification
Setup
1. Set a zero slope using a laser.
2. Set up a string line the length of the machine’s reach, and then set up the string level.
3. Utilize the measure slope feature to perform the following test. For more information on the Measure
Slope function, refer to the
3D-MC User's Manual P/N 1013510-01
Tes t
1. Extend the machine implements so that the bucket is at the far end of the string line.
2. Lower the bucket to the string, and tap OK on the Measure first point screen of the Measure
Slope feature in 3D-MC.
3. Retract the machine implements so that the bucket is at the near end of the string.
4. Lower the bucket to the string and tap OK on the Measure second point screen of the Measure
Surface feature. The sloping surface created by 3D-MC should match the slope of the string line as
set by the laser.
It is your responsibility to be completely familiar with the cautions described in these
installation instructions. These messages advise against the use of specific methods or
procedures, which can result in personal injury, damage to the equipment, or unsafe
operating conditions. Remember, most accidents are caused by failure to observe basic
safety precautions.
