SPECIFICATIONS
2-2
TX 413 Service Manual
• Hydraulic Flow & Pressure Tester (Hydro-Gear BDP) Bi-directional Flow Test Kit (P/N 70661) or
equivalent
• 15º/60º Offset Open End Wrench, 1/8" and 15/16"
• Torque Wrenches - nominal torque ranges, plus one capable of 300 ft-lbs. (407 Nm)
• Multimeter
Special Tools
General Specifications
Dimensions:
Item Specification
Engine Honda Model GX390 13 horsepower, 4-cycle, air cooled, single cylinder, overhead
valves, 12 VDC solenoid shift starter, 10 amp alternator, and low oil shut down.
RPM Setting No-load Speed - 3600 rpm + 150 rpm
Low Idle Speed - 1450 rpm + 150 rpm
Spark Plug NGK BPR6ES, Denso W20EPR-U or equivalent. Air Gap: 0.030 inch (0.76mm).
Oil Capacity 1.16 Quarts (1.1 liter)
Fuel Tank 3 Gallons (11.4 liter)
Fuel shut off Frame mounted electric fuel shut off
Item Specification
Overall Length (without Bucket) 66.1" (167cm)
Overall Length (with Bucket) 86.7" (220cm)
Overall Width (without Bucket) 33.7" (85.6cm)
Overall Width (with Bucket) 34.5" (87.6cm)
Overall Machine Height (Bucket
Lowered)
42.5" (107.9cm)
Overall Operating Height (Fully
Raised Bucket)
76.4" (194cm)
Wheel Base 31.1" (78.9cm)
Ground Clearance (Maximum) 6.1" (15.5cm)
Ground Clearance (Minimum) 3.8" (9.7cm)
Dump Angle 45°
Bucket Roll Back (Ground Position) 25.2°
Bucket Roll Back (Carry Position) 25.2°
