Rev. 000
SPECIFICATIONS
2-4
TX 413 Service Manual
Track System:
Performance:
Periodic Maintenance Items:
Note: Refer to Section 2 and the TX 413 and engine operator manuals for additional information.
Item Specification
Track The tracks are Kevlar reinforced, endless rubber rings with 28 internal lugs. The outer
tread on the tracks is a turf-friendly S-shaped pattern with pitched crosscuts.
Track Width: 5.88 inches (14.9cm)
Track Pitch: 3.45 inches (8.8cm)
Drive Wheel The drive wheels are single-piece, austempered ductile iron, “squirrel cage” castings.
Wheel Diameter: 11.63 inches (29.5cm)
Road Wheels Constant track ground pressure is maintained by 20 ductile iron road wheels. The road
wheels each have a sealed bearing that are protected by a secondary dirt seal on the
inside and a gasketed steel cap on the outside.
Item Specification
Tip Capacity 1200 lbs. (544.3kg)
Operating Capacity SAE J818 rating 35% tip capacity 420 lb (190.5kg)
SAE J818 rating 50% tip capacity 600 lb (272.2kg)
Speed Forward 0 - 3 mph (0 - 4.8km/hr)
Reverse 0 - 1.5 mph (0 - 2.4km/hr)
Weight 1340 lbs. (607.8kg) (traction unit only)
1440 lbs. (653.2kg) (with Dingo TX bucket)
Item Specification Maintenance Interval
Grease Lithium Base NLGI2 (National Lubricating
Grease Institute.)
Every 8 hrs. or after every washing
Hydraulic Oil 10w30 CH4 rating - 10 gal. (37.8 liters) Check daily - change at 400 hrs.
Hydraulic Filter Spin on Initially, 8 hrs., then every 200 hrs.;
more often when used in dusty,
dirty conditions
Engine Oil No filter, 10w30, SJ Rating, 1.16 qts (1.1 liters) /
5w-20 or 5w-30 below 32º
F (0º C)
Check daily - change at 100 hrs.;
more often when used in dusty,
dirty conditions.
Engine Air Filter Paper element with foam prefilter Check every 50 hrs.; more often
when used in dusty, dirty conditions
