Toro Dingo TX 413 - Valve Reference Drawings

Rev. 000
TX 413 Service Manual
6-3
HYDRAULIC SYSTEM
Principal Hydraulic Lines
Loader Arm Hydraulic Lines
Line “2”
Line “H”
Line “I”
Line “3”
Line “E”
Line “D”
Line “C”
Line “B”
Line “A”
Line “4”
Line “1”
Valve Reference Drawings
