Rev. 000
ENGINE
Starter Service
Serial numbers 200000200 and higher have an
opening for easier access to the starter (Fig. 081).
Figure 081 DSC-0583
Manual Shutoff
This engine also has the manual fuel shut off on the
carburetor (Fig. 082).
Figure 082 manual shutoff
4-18
TX 413 Service Manual
5. Install the vent hose on the oil filter bracket (Fig.
080).
Figure 080 DSC-1095
6. Install the positive battery cable, then the
negative cable.
7. Install the rear cover.
8. Start the unit and check for any fuel leaks.
Remove the hydraulic cylinder lock on the lift
cylinder and lower the lift arm.
