TX 413 Service Manual
9-3
TESTING
Figure 537 DSC-0580
C. Couplers
Coupler End – 7/8”-14 UNF-2B O-ring Seal (Fig. 537).
Figure 538 DSC-0577
Test Gauge – 3/4”-16 – 37° Female (Fig. 538).
Figure 539 DSC-0585
Coupler Adaptor Kit 106-7695. Converts the 3/4”
coupler to the 3/8” coupler (Fig. 539).
A. P/N 100-4701 - Female coupler
B. P/N 104-6134 - Male coupler
Test hoses:
Diameter Length PSI Rated
- 8 3' 5000
A
B
