g002369
Figure4
1.Left,rearcornerofbed4.Clevispin
2.Vehicleframechannel
5.Lynchpin
3.Pivotplate
7.Liftthebedoffthevehicle.
8.Stowtheliftcylindersinstorageclips.
2
PreparingtoInstallthe
TankSkid
Partsneededforthisprocedure:
1
RearPTOKit,Heavy-DutyWorkmanVehicle
(HD-SeriesModelswithaManualTransmission)
1
MultiProWMTurfSprayerFinishingKit,Manual
WorkmanUtilityVehicle(HD-SeriesModelswitha
ManualTransmission)
1
MultiProWMTurfSprayerFinishingKit,Manual
WorkmanUtilityVehicle(HD-SeriesModelswitha
ManualTransmission)
1
MultiProWMTurfSprayerFinishingKit,Automatic
WorkmanUtilityVehicle(HDX-AutoModel)
InstallingtheRearPTOKitfor
HeavyDutyWorkmanVehicles
(HD-SeriesModelswithaManual
Transmission)
ForHD-andHDX-SeriesWorkmanmodelswith
amanualtransmission,fullyinstalltheRearPTO
KitforHeavy-DutyWorkmanVehicles;refertothe
InstallationInstructionsfortheRearPTOKitforHeavy
DutyWorkmanVehicles.
High-FlowHydraulicsKit,
WorkmanHDX-AutoUtilityVehicle
(Non-TC—HDX-AutoModel)
FullyinstalltheHigh-FlowHydraulicsKitforWorkman
HDX-AutoUtilityVehicles;refertotheInstallation
InstructionsfortheHigh-FlowHydraulicsKit,
WorkmanHDX-AutoUtilityVehicle.
LiftingtheSprayerSkid
Usingliftingequipmentwitha408kg(900lb)lift
capacity,liftthetankskidfromtheshippingcrateat
the2frontand2rearliftpoints(Figure5).
Note:Ensurethatthetankskidisraisedhighenough
toinstallthejackstands.
g023738
Figure5
1.Rearliftpoint2.Frontliftpoint
MultiProWorkmanTurfSprayer
FinishingKit(HD-SeriesModels
withaManualTransmission)
ForHD-andHDX-SeriesWorkmanmodelswith
amanualtransmission,completethestepsinthe
MultiProWMTurfSprayerFinishingKitforManual
WorkmanUtilityVehicles;refertotheInstallation
InstructionsfortheMultiProWMTurfSprayer
FinishingKit,ManualWorkmanUtilityVehicle.
MultiProWorkmanTurfSprayer
FinishingKit(HDX-AutoModel)
HDX-AutomaticSeriesWorkmanmodels,complete
thestepsintheMultiProWMTurfSprayerFinishing
17
