InstallingtheCenterBoom-Section
Hose
1.Routethecenterboom-sectionhoseasshown
inFigure44.
g028471
Figure44
1.Up
4.Center-boomhose
2.T-tting5.Center-sectionvalve
3.Hoseclamp
6.Frontofthemachine
2.Installtheboomsectionhoseoverthebarbed
T-ttingatthecenterboomsectionandsecure
thehosewithahoseclamp(Figure44).
Note:Applyacoatofliquidsoaptothehose
barboftheteettingtoeaseinstallationofthe
hose.
17
InstallingtheNozzles
NoPartsRequired
Procedure
Thenozzlesthatyouusetoapplyyourchemicals
varydependingontherateofapplicationthatyou
need;therefore,nozzlesarenotsuppliedwiththekit.
Toobtainthecorrectnozzlesforyourneeds,contact
yourAuthorizedToroDistributorandbepreparedto
givethemthenfollowinginformation:
•Thetargetapplicationrateinlitersperhectare,US
gallonsperacre,orUSgallonsper1,000square
feet.
•Thetargetspeedofthevehicleinkilometersper
hourormilesperhour.
1.Threadorinsertthenozzleintothenozzle
receptaclefollowedbyagasket.
2.Slidethenozzlereceptacleoverthenozzle
ttingonaturret.
3.Turnthenozzleclockwisetolockthecamson
thereceptacleinplace.
4.Verifythefanportionofthenozzle.
SeetheInstallationInstructionsaccompanyingthe
nozzlesformoreinformation.
18
InstallingtheFreshwater
Tank
Partsneededforthisprocedure:
1Freshwatertank
1
90°elbow(3/4inchNPT)
1
90°spigot
1Freshwater-tankmount
4Mountstrap
4
Flange-headbolt(5/16x5/8inch)
10
Flangelocknut(5/16inch)
1
Supporttube(freshwatertank)
1
Jamnut(5/16inch)
1
Bolt(5/16x1inch)
2
Shoulderbolt(1/2x1-15/16inches)
2
Bolt(5/16x2-1/4inch)
2
Washer(5/16inch)
AssemblingtheMountBracketto
theFreshwaterTank
1.Assemblethefreshwatertanktothe
freshwater-tankmountwiththe2mountstraps,
4ange-headbolt(5/16x5/8inch),and4ange
locknuts(5/16inch)asshowninFigure45.
Note:Ensurethattheelbowandspigotare
alignedtothesamesideofthetankasthe
freshwater-tankdecal.
36
