KitforAutomaticWorkmanUtilityVehicles;referto
theInstallationInstructionsfortheMultiProWMTurf
SprayerFinishingKit,AutomaticWorkmanUtility
Vehicle.
3
InstallingtheHold-Down
BracketsfortheTankSkid
Partsneededforthisprocedure:
2Hold-downbrackets
Procedure
1.Removethe2rearange-headboltsand2
angelocknutsthatsecurethesupportbracket
fortheenginetubetotheframeofthemachine
(Figure6).
Note:Retainthefastenersforlateruse.
g028410
Figure6
1.Rearhole—support
bracket(enginetube)
4.Enginesupporttube
2.Flangelocknut
5.Liftcylinder
3.Flange-headbolt
2.Rotatetheliftcylindertoprovideclearanceto
installthehold-downbracketforthetankskid
(Figure6).
3.Assemblethehold-downbracketstosupport
bracketandframetheusingthe2ange-head
boltsandangelocknutsremovedinstep1
(Figure7).
g028421
Figure7
1.Supportbracket(engine
tube)
3.Flanged-headbolts
2.Hold-downbracket(tank
skid)
4.Liftcylinder
4.Torquetheboltsandnutsto91to113N∙m(67
to83ft-lb).
5.Repeatsteps1to4attheoppositesideofthe
machine.
18
