g028857
Figure57
1.Sprayerpump
Specications
Note:Specicationsanddesignaresubjectto
changewithoutnotice.
Spraysystembaseweight
(vehicleweightnotincluded)
424kg(935lb)
Tankcapacity
757L(200USgallons)
Overallvehiclelengthwiththe
standardspraysystem
422cm(166inches)
Overallvehicleheightwith
standardspraysystemtothe
topofthetank
147cm(58inches)
Overallvehicleheightwith
standardspraysystemand
theboomsstoredintheX
pattern
234cm(92inches)
Overallvehiclewidthwiththe
standardspraysystemand
theboomsstoredintheX
pattern
175cm(69inches)
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
Note:Ifyouneedtotransportthevehicleonatrailer
withthesprayerinstalled,makesurethatthebooms
aretieddownandsecure.
ThinkSafetyFirst
Pleasecarefullyreadallofthesafetyinstructionsand
decalsinthesafetysection.Knowingthisinformation
couldhelpyouorbystandersavoidinjury.
UsingtheInfoCenter
TheInfoCenterLCDdisplayshowsinformationabout
yourmachine,suchastheoperatingstatus,various
diagnostics,andotherinformationaboutthemachine
(Figure58).Thereisasplashscreenandmain
informationscreenontheInfoCenter.Youcanswitch
betweenthesplashscreenandmaininformation
screen,atanytime,bypressinganyoftheInfoCenter
buttonsandthenselectingtheappropriatedirectional
arrow.
g020650
Figure58
1.Indicatorlight3.Middlebutton
2.Rightbutton
4.Leftbutton
•Leftbutton,Menuaccess/Backbutton—press
thisbuttontoaccesstheInfoCentermenus.You
canalsouseittobackoutofanymenuyouare
currentlyusing.
•Middlebutton—usethisbuttontoscrolldown
menus.
•Rightbutton—usethisbuttontoopenamenu
wherearightarrowindicatedadditionalcontent.
Note:Thepurposeofeachbuttonmaychange
dependingonwhatfunctionisactiveatthetime.The
44
