Toro Multi Pro WM - Cleaning the Sprayer Valves

CleaningtheSprayer
Valves
•Tocleantheratecontrolvalve,refertothe
followingsections:
1.RemovingtheValveActuator(page76)
2.RemovingtheRateControlManifoldValve
(page77)
3.CleaningtheManifoldValve(page81)
4.AssemblingtheManifoldValve(page82)
5.InstallingtheRateControlManifoldValve
(page83)
6.InstallingtheValveActuator(page86)
•Tocleantheagitationvalve;refertothefollowing
sections:
1.RemovingtheValveActuator(page76)
2.RemovingtheAgitationManifoldValve
(page78)
3.CleaningtheManifoldValve(page81)
4.AssemblingtheManifoldValve(page82)
5.InstallingtheAgitationManifoldValve(page
83)
6.InstallingtheValveActuator(page86)
•Tocleanthemaster-boomvalve,refertothe
followingsections:
1.RemovingtheValveActuator(page76)
2.RemovingtheMasterBoomManifoldValve
(page79)
3.CleaningtheManifoldValve(page81)
4.AssemblingtheManifoldValve(page82)
5.InstallingtheMasterBoomManifoldValve
(page84)
6.InstallingtheValveActuator(page86)
•Tocleanthe3sectionvalves;refertothefollowing
sections:
1.RemovingtheValveActuator(page76)
2.RemovingtheSectionManifoldValve(page
80)
3.CleaningtheManifoldValve(page81)
4.AssemblingtheManifoldValve(page82)
5.InstallingtheSectionManifoldValve(page
85)
6.InstallingtheValveActuator(page86)
RemovingtheValveActuator
1.Parkthemachineonalevelsurface,engagethe
parkingbrake,shutoffthepump,shutoffthe
engine,andremovethekey.
2.Removethe3-pinconnectorofthevalve
actuatorfromthe3socketelectricalconnector
ofthesprayerharness.
3.Removetheretainerthatsecurestheaactuator
tothemanifoldvalvefortheratecontrol
valve,agitationvalve,master-boomvalve,or
boom-sectionvalve(Figure109).
Note:Squeezethe2legsoftheretainer
togetherwhilepushingitdown.
Note:Retaintheactuatorandretainerfor
installationinInstallingtheValveActuator(page
86).
g028237
Figure109
Sectionvalveactuatorshown(theagitation-valveactuator
issimilar)
1.Valveactuator(section
valveshown)
3.Stemport
2.Retainer
4.Removetheactuatorfromthemanifoldvalve.
76
