Hopper Dump Lever
Move the lever rearward to dump the clippings from
the hopper ( Figure 13 ).
Move the lever forward to close the hopper after
dumping.
Key Switch
The key switch has 3 positions: O FF , O N /P REHEAT ,
and S TART .
Note: If the engine stops running and the key switch
is in the O N /P REHEAT position, and you leave the
operator's seat, after a short delay a buzzer will sound
to alert you to turn the key to the O FF position.
T rimming Edge Indicator
The cutting unit has 2 slots that indicate the actual
cutting width of the blades; refer to Figure 14 .
g437793
Figure 14
1. Slot
21
