Checking the Hydraulic-Fluid
Level
Service Interval : Before each use or daily
1. Park the machine on a level surface.
2. Ensure that the hopper is fully lowered and level
and the cutting unit is lowered.
3. Disengage the PT O, engage the parking brake,
shut of f the engine, and remove the key .
4. Remove the dipstick from hydraulic tank and
wipe the dipstick with a clean cloth ( Figure 81 ).
g435826
Figure 81
5. Insert the dipstick into the ll tube and thread
the dipstick cap onto the tube.
6. Remove the dipstick and check the uid level
( Figure 82 ).
The hydraulic uid level is normal when the uid
is indicated between the 2 marks in the dipstick.
g435827
Figure 82
7. If the uid level is below the lower mark in the
dipstick, add the specied hydraulic uid into the
ll tube ( Figure 82 ) until you can see that the
uid level is between the 2 marks the dipstick.
Important: Do not ll the hydraulic tank
with hydraulic uid above the upper mark in
the dipstick.
g435828
Figure 83
8. Thread the dipstick ll cap onto the ller tube.
Note: Do not tighten the cap with a wrench.
9. Check all hoses and ttings for leaks.
Changing the Hydraulic Fluid and
Filter
Service Interval : After the rst 100 hours —Replace
the hydraulic uid and lter .
Every 400 hours —Replace the hydraulic uid
and lter .
Hydraulic-reservoir capacity: approximately 6.7 L
(7.1 US qt)
1. Park the machine on a level surface.
2. Ensure that the hopper is fully lowered and level
and the cutting unit is raised.
3. Disengage the PT O, engage the parking brake,
shut of f the engine, and remove the key .
4. Place a pan under the hydraulic pump on the
right side to collect the hydraulic uid.
5. T o empty the hydraulic tank, remove the cover
and loosen the hydraulic hose on the side of the
hydraulic pump. ( Figure 84 ).
