3. Start engine. Verify pinion shaft or traction shaft
(4WD units) speed (RPM) with phototac. Check corre-
sponding speed on the speedometer (Fig. 39 and 40)
4. Turn off engine. Replace meter as necessary.
Pinion Speed (RPM)
Speedometer (MPH)
291.2 4
582.4 8
873.6 12
1. Traction shaft (4WD) 2. Differential housing
Figure 40
1
2
Reels Enable/Disable and Backlap Switches
The reels enable/disable switch is attached to the instru-
ment panel. It is a three position switch that is main-
tained in any of its three positions. Positioning the toggle
back closes the switch between the back (brown wire)
and center (black wire) terminals. Positioning the toggle
forward closes the switch between the front (orange
wire) and center terminals (Fig. 41).
The backlap switch is under the seat. It is a three posi-
tion switch that is maintained in any of its three positions.
Positioning the toggle to the right closes the switch be-
tween the right (white wire) and center (black wire) ter-
minals. Positioning the toggle to the left closes the
switch between left (blue wire) and center terminals
(Fig. 42).
1. Reel enable/disable
switch
2. Instrument panel
Figure 41
2
1
FRONT
RIGHT
1. Backlap switch 2. Radiator shield
Figure 42
1
2
REAR
RIGHT
Figure 43
Electrical
System
