Toro Reelmaster 5200-D Service Manual

Rev. A
Reelmaster 5200-D/5400-D4WD Rear Axle Page 9 - 8
(Unit Serial No. 80001 - 99999)
4WD Rear Axle
Note: For information on 2WD rear axle service and repairs, see Chapter 7–Steering and Brakes in this manual.
1. Rear axle assembly
2. Steering cylinder
3. Hydraulic hose
4. Tie rod
5. Steering plate
6. Rear wheel
7. Lug bolt
8. Rear wheel spacers
9. Pivot pin screw
10. Pivot pin
11. Washer
Figure 10
5
6
7
8
1
10
5
9
3
3
2
4
11
11
