Toro Reelmaster 5200-D Service Manual

Reelmaster 5200-D/5400-DHydraulic System Page 4 - 10
Hydraulic Flow Diagrams
Traction Circuit (Forward Direction Shown)
High Pressure Low Pressure (Charge) Return or Suction Flow
Reelmaster 5200-D/5400-D
SYSTEM PRES SURE
CHARGE PRES SURE
150 PSI
3625 PSI
70 PSI
3625 PSI
70 PSI
OIL
FILTER
SYSTEM
RELIEF
SYSTEM
RELIEF
COOLER
BY-P AS S
FILTER
BY-P AS S
CHARGE
PRES SURE
RELIEF
HEA T
EX CHANGER
IN-LINE
STRAINER
DIFFERENTIAL
HOUSING
INPUT
SHAF T
OUTPUT
SHAF T
SYSTEM
PRES SURE
(FORW ARD)
(REVERSE)
