Toro Reelmaster 5200-D Service Manual

Reelmaster 5200-D/5400-DHydraulic System Page 4 - 2
Specifications
Item
Description
Hydraulic Transmission Sauer-Sundstrand M25, U-type
System Relief Pressure (Forward & Reverse) 3625 PSI (249.9 bar)
Charge Pressure 150 PSI (10.3 bar)
Cooler By-pass Pressure 70 PSI (4.8 bar)
Filter By-pass Pressure 70 PSI (4.8 bar)
Oil Filter Screw-on type
In-line Strainer 260 micron, 8 GPM (30.3 LPM)
Gear Pump 3 section, positive displacement gear type pumps
Maximum Operating Pressure 3000 PSI (207 bar)
Steering Relief Pressure 1250 PSI (86.2 bar)
Hydraulic Manifold Block
Front Reels Circuit Relief Pressure (R1) 3000 PSI (207 bar)
Rear Reels Circuit Relief Pressure (R2) 2000 PSI (138 bar)
Reel Motor s Gear motor
Maximum Operating Pressure 3000 PSI (207 bar)
Hydraulic Filter (Reels, Lift, and Steering Circuits) 5 Micron spin-on cartridge type
Hydraulic Reservoir (Reels, Lift, and Steering Circuits) 8.5 gal. U.S. (32.2 L)
Hydraulic Oil See Check Hydraulic System Fluid in General Information section
Hydraulic Reservoir in Differential Housing (Transmission) 5.0 qts. U.S. (4.7 L)
