54 GX9 ASD Installation and Operation Manual
F EEDBACK
Feedback Settings
PID Feedback Differential (D) Gain F366
PG Settings
Number of PG Pulses F367
PG Phases F368
PG Disconnection Detection F369
Electronic Gear Setting F370
Position Loop Gain F371
Positioning Completion Range F372
Frequency Limit at Position F373
Current Control Proportional Gain F374
Current Control Integral Gain F375
Speed Loop Proportional Gain F376
Speed Loop Integral Gain F377
Motor Counter Data F378
Speed Loop Parameter Ratio F379
Drooping Control
Drooping Gain F320
Speed at Drooping Gain 0% F321
Speed at F320 Drooping Gain F322
Drooping Insensitive Torque F323
Drooping Output Filter F324
Drooping Reference F327
Load Inertia (Acc/Dec Torque) F325
Load Torque Filter F326
Override Control
Adding Input F660
Multiplying Input F661
CN8 Option Override Multiplication Gain F729
C OMMUNICATIONS
Communication Settings
ASD Number F802
TTL Baud Rate F800
RS232/RS485 Baud Rate F820
Parity F801
RS232/RS485 Communication Time Out
Time
F803
TTL and RS232/RS485 Communication
Time Out Action
F804
TTL Send Wait Time F805
RS232/RS485 Wire Count F821
RS232/RS485 Send Wait Time F825
TTL ASD-to-ASD Communication F806
RS232/RS485 ASD-to-ASD Communication F826
EOI Port Address (Reset ASD after change) N/A
Program Menu Navigation
Primary Menu Sub Menu Parameter Name
Parameter
Number
EOI P
o
Address
