OPERATOR’S MANUAL
series Robot Controller
5.2.5 Quitting Data Editing [SAVE]
(1) Function
Saves an edited data in a file and quits editing data.
(2) Procedures
(a) Step 1: Save data.
Select the data display mode as shown below (i.e., the cursor is not present
on the command line).
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 5 = 300 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
P O I N T 0 0 0 0 5 w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
Press [SAVE], and the system asks with a confirmation message if you wish
to save the edited data.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 5 = 300 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
[ S A V E ] O K T H E N < E X E > w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
STE 80720
– 5-16 –
