5.2.14 Cut of Positional Data [CUT]
(1) Function
Cuts multiple positional data simultaneously.
(2) Procedures
Assume that you are going to cut the positional data of "POINT00004" ~
"POINT00005".
(a) Step 1: Command selection.
Move the main cursor to "POINT00004" and press the NEXT key repeatedly
until [CUT] is displayed in the command menu.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 200 , 200 , 2 00 ,
P O I N T 0 0 0 0 5 = 300 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
P O I N T 0 0 0 0 4 w / . w o r l d
< N O S A V F I N D T E A C H M - T O C U T >
Press [CUT], and the entire data at the main cursor position is displayed in a
reversed image to indicate that it is selected. The display is as shown below.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 5 = 300 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
P O I N T 0 0 0 0 4 w / . w o r l d
C U T
The entire data selected is displayed inversely.
