5.2.8 Call of Detailed Positional Data Display [FULL]
(1) Function
Displays the detailed positional data display.
(2) Procedures
Assume that you are going to display the data of "POINT00005" in detail.
(a) Step 1: Command selection.
Move the main cursor to "POINT00005", and the following display appears.
P O I N T X Y Z
↑
P O I N T 0 0 0 0 3 = 1 0 0 , 1 0 0 , 1 0 0 ,
P O I N T 0 0 0 0 4 = 2 0 0 , 2 0 0 , 2 0 0 ,
P O I N T 0 0 0 0 5 = 300 , 300 , 3 00 ,
P O I N T 0 0 0 0 6 = 4 0 0 , 4 0 0 , 4 0 0 ,
↓
P O I N T 0 0 0 0 7 = 5 0 0 , 5 0 0 , 5 0 0 ,
P O I N T 0 0 0 0 5 w / . w o r l d
S A V E P R G F U L L T R A N S P Y L D >
Press [FULL] and the following detailed display is called.
P O I N T 0 0 0 0 5 [ 5 / 10]
X : 3 0 0 . 0 0 0 C O N F I G : F R E E
Y : 3 0 0 . 0 0 0
Z : 3 0 0 . 0 0 0
C : 3 0 0 . 0 0 0
T : 3 0 0 . 0 0 0
P O I N T 0 0 0 0 5 w / . w o r l d
S A V E P R G D I R T R A N S P Y L D >
(3) Caution
Even if the main cursor is located under the column of a data element you wish
to display in detail, the detailed display appears as well.
For details of operations to be done on the detailed display, see Para. 5.3.
