OPERATOR’S MANUAL
series Robot Controller
Section 5 Data Editing
The data editing function allows input and editing of positional data, coordinate data and
load data. Each data is saved in a file together with a program, and can be edited on
the file basis.
5.1 Starting Up the Data Editor
The data editor can be started up in one of the following two (2) manners.
1. [DEDIT] of basic menu
2. [DEDIT] of program editing menu
For the startup procedures from the program editing menu, see Section 4.
This section describes the startup procedures from the basic menu.
(1) Procedures
(a) Step 1: File selection screen display.
Call the basic display as shown below.
M O D E : T E A C H I N G / C O N T
L :
O : 20%
M : F R E E
S : STOP
R ESET
E D I T D E D I T S E L C T F I L E >
Press [DEDIT].
E D I T [ 0 0 1 / 0 1 0 ]
P R G 1 1 0 0 0 S e p - 0 1 ― 2008
P R G 2 1 4 5 S e p - 0 1 ― 2008
T E S T 1 100 Sep - 0 2 ― 2008
T E S T 2 1 0 0 S e p - 0 2 ― 2008
T E S T 3 1 2 3 4 5 S e p - 0 3 ― 2008
N A M E T I M E N E W
For details on the file selection screen, see Section 4.
STE 80720
– 5-1 –
To Next Page
