OPERATOR’S MANUAL
series Robot Controller
Operations of each menu are shown below.
Menu Descriptions
[SAVE] Used to save a data and quit the data editor.
(When the data editor was started up from the program editor, the
program editor terminates also.)
[PRG] Used to select the program editor display. If the data editor was
started up, however, the display will not change over.
[TRANS] Used to select the coordinate data display.
[POINT] Used to select the positional data display.
[FIND] Used to search a mode name.
[NOSAV] Used to quit the editor without saving data. All changed data are
aborted.
(When the data editor was started up from the program editor, the
program editor terminates also.)
[CUT] Used to select the range select mode.
[PASTE] Used to paste the contents saved in the cut buffer (i.e., data
deleted by the previous cut menu) after a load data indicated by
the main cursor to clear the cut buffer.
Each menu of [SAVE], [PRG], [FIND], [NOSAV], [CUT] and [PASTE] is the same as
in the positional data directory display mode and is not described in this paragraph.
STE 80720
– 5-82 –
