7.7.4 Output Signal Reset
(1) Function
Sets off all user external output signals (DOUT (1) ~ DOUT (164)). The hand
signals (201 ~ 204) will not turn off.
(2) Procedures
(a) Step 1: Command selection.
Press the NEXT key repeatedly until [RESET] is displayed in the menu, and
press the corresponding function key.
M O D E : I N T E R N A L
/
C O N T T E S T P R O
L : 28
O : 1 00%
M : F REE
S : S TOP
C ONT
S E L M O D E O V R D R E S E T >
Select [SIG].
M O D E : I N T E R N A L / C O N T T E S T P R O
L : 28
O : 1 00%
M : F REE
S : S TOP
C O NT
R E S E T : S I G
P R O G C Y C L E S T E P S I G S E L
(b) Step 2: Input through EXE key.
Make sure that your entry is correct, and press the EXE key.
M O D E : I N T E R N A L
/
C O N T T E S T P R O
L : 28
O : 1 00%
M : F REE
S : S TOP
C ONT
S E L M O D E O V R D R E S E T >
