OPERATOR’S MANUAL
series Robot Controller
Keys operative in this mode and their operations are shown below.
Key Descriptions
↑
Used to display the contents which are just one (1) line before
the cursor line.
↓
Used to display the contents which are just one (1) line after
the cursor line.
ALT + ↑
Used to display the contents of the just preceding page.
ALT + ↓
Used to display the contents of the just succeeding page.
F1
Used to sort the data by file name.
F2
Used to sort the data by date.
ESC
Used to return the system to the previous display.
(3) Cautions
• If a USB drive is selected in any of the operation processes, the USB drive
will not be recognized unless there is a "TS3000" folder (directory) in the drive.
Therefore, before performing any file operations, check that there is a TS3000
folder (directory) in the USB drive.
• If there is no TS3000 folder (directory) in the USB drive, create one.
STE 80720
– 9-3 –
