STE 80720
– 10-20 –
OPERATOR’S MANUAL
series Robot Controller
Operations of each menu are shown below.
Menu Descriptions
[END] Used to quit coordinate selection and to return to the utility
display.
[DIR] Used to select coordinate data directory display.
[WORK] Used to specify the coordinate system displayed to the work
coordinate system and cancel the designation.
[TOOL] Used to specify the coordinate system displayed to the tool
coordinate system and cancel the designation.
[FIND] Used to search a coordinate name.
(3) Cautions
• The world coordinate system cannot be displayed in detail.
• Each menu, END, WORK, TOOL, FIND is process in the same manner as for
the directory display.
To Next Page
