Keys operative in this mode and their operations are shown below.
Key Descriptions
←
Used to move the cursor left on the command line.
→
Used to move the cursor right on the command line.
Numeral
Alphabet
Used to input characters on the command line.
EXE
Used to search the specified position name and return the
system to the coordinate data directory display.
Unless the specified data is present, a message saying "Not
found" is displayed on the command line.
INS
Used to select the insert or replace mode for the command
line.
BS
Used to delete one (1) character just before the cursor position
on the command line.
ALT +BS
Used to delete one (1) character at the cursor position on the
command line.
ESC
This function works in a different manner according to the
presence or absence of input character(s).
Presence of input character(s): All input character(s) on the
command line are cleared.
Absence of input character(s): The system returns to the
coordinate data directory display.
Press the EXE key, and search for the specified name. If found, the
coordinate data directory is displayed with the specified data at the head of
the screen and the main cursor moved there. The display is as shown
below.
T R A N S S E L E C T I O N [ 9 / 1 1 ]
T R A N S 0 0 0 0 8 1 0
T R A N S 0 0 0 0 9 1 0
T R A N S 0 0 0 1 0 6
T R A N S 0 0 0 0 8
E N D F U L L F I N D W O R K T O O L
To Next Page
