STE 80720
– 10-30 –
OPERATOR’S MANUAL
series Robot Controller
Keys operative in this mode and their operations are shown below.
Key Descriptions
↑
Used to move the cursor up. The command line is cleared.
↓
Used to move the cursor down. The command line is
cleared.
←
Used to move the cursor to the left. The command line is
cleared.
→
Used to move the cursor to the right. The command line is
cleared.
Numeral
Used to input characters on the command line.
EXE
Used to change the data indicated by main the cursor to the
input value.
BS
Used to delete one (1) character just before the cursor position
on the command line.
ALT +BS
Used to delete one (1) character at the cursor position on the
command line.
ESC
Used to return the system to the utility display.
(b) Step 2: Data input.
Move the main cursor to a data you wish to change, and enter a new data.
Character input to the command line is always effective.
W O R K T I M E U T I L I T Y
P O W E R O N T I M E 1 2 3 4 5 H 1 2 H
P R O G R A M R U N T I M E 0 0 0 0 0 H 0 0 H
H O U R ? [ 0 - 9 9 9 9 9 ] : 1 0 0
