[51] Comparator 5 Use the result of comparator 5 in the logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic rule.
[70] SL Time-out 3 Use the result of timer 3 in the logic rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic rule.
[73] SL Time-out 6 Use the result of timer 6 in the logic rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic rule.
[80] No Flow
[81] Dry Pump
[82] End of Curve
[83] Broken Belt
13-03 Reset SLC
Option: Function:
[0] * Do not reset SLC Retains programmed settings in all group 13 parameters (13-*).
[1] Reset SLC Resets all group 13 parameters (13-*) to default settings.
13-1* Comparators
Comparators are used for comparing continuous variables (i.e. output frequency, output current, analog input
etc.) to fixed preset values. In addition, there are digital values that will be compared to fixed time values. See
explanation in par.13-10
Comparator Operand. Comparators are evaluated once in each scan interval. Use the
result (TRUE or FALSE) directly. All parameters in this parameter group are array parameters with index 0 to 5.
Select index 0 to program Comparator 0, select index 1 to program Comparator 1, and so on.
13-10 Comparator Operand
Array [4]
Option: Function:
Select the variable to be monitored by the comparator.
[0] * DISABLED
[1] Reference
[2] Feedback
[3] Motor speed
[4] Motor current
[5] Motor torque
[6] Motor power
[7] Motor voltage
[8] DC-link voltage
[9] Motor thermal
[10] Drive thermal
[11] Heat sink temp.
[12] Analog input AI53
[13] Analog input AI54
[14] Analog input AIFB10
[15] Analog input AIS24V
Parameter Description
140 TR200 Programming Guide
