[1656] Feedback 3 [Unit]
[1660] Digital Input
[1662] Analog Input 53
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[3110] Bypass Status Word
15-11 Logging Interval
Range: Function:
0.000 N/
A*
[0.000 - 0.000 N/A] Enter the interval in milliseconds between each sampling of the variables
to be logged.
15-12 Trigger Event
Option: Function:
Selects the trigger event. When the trigger event occurs, a window is
applied to freeze the log. The log will then retain a specified percentage
of samples before the occurrence of the trigger event (par.15-14
Samples
Before Trigger).
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
Parameter Description
TR200 Programming Guide 163
