16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control words.
16-80 Fieldbus CTW 1
Range: Function:
0 N/A* [0 - 65535 N/A] View the two-byte Control word (CTW) received from the Bus-Master.
Interpretation of the Control word depends on the fieldbus option instal-
led and the Control word profile selected in par.8-10
Control Profile.
For more information please refer to the relevant fieldbus manual.
16-82 Fieldbus REF 1
Range: Function:
0 N/A* [-200 - 200 N/A] View the two-byte word sent with the control word form the Bus-Master
to set the reference value.
For more information please refer to the relevant fieldbus manual.
16-84 Comm. Option STW
Range: Function:
0 N/A* [0 - 65535 N/A] View the extended fieldbus comm. option status word.
For more information please refer to the relevant fieldbus manual.
16-85 FC Port CTW 1
Range: Function:
0 N/A* [0 - 65535 N/A] View the two-byte Control word (CTW) received from the Bus-Master.
Interpretation of the control word depends on the fieldbus option instal-
led and the Control word profile selected in par.8-10
Control Profile.
16-86 FC Port REF 1
Range: Function:
0 N/A* [-200 - 200 N/A] View the two-byte Status word (STW) sent to the Bus-Master. Interpre-
tation of the Status word depends on the fieldbus option installed and
the Control word profile selected in par.8-10
Control Profile.
16-9* Diagnosis Read-Outs
Parameters displaying alarm, warning and extended status words.
16-90 Alarm Word
Range: Function:
0 N/A* [0 - 4294967295 N/A] View the alarm word sent via the serial communication port in hex code.
16-91 Alarm Word 2
Range: Function:
0 N/A* [0 - 4294967295 N/A] View the alarm word 2 sent via the serial communication port in hex
code.
16-92 Warning Word
Range: Function:
0 N/A* [0 - 4294967295 N/A] View the warning word sent via the serial communication port in hex
code.
Parameter Description
178 TR200 Programming Guide
