16 Tracer AdaptiView Display Operations Guide • CTV-SVU01B-EN
Alarms
You can use the Tracer AdaptiView display to view alarms and to reset them. Alarms are
communicated to the display immediately upon detection.
Viewing the Alarms Screen
Tou ch t he Alarms button in the main menu area (Figure 1, p. 7) to view the Alarms screen.
A table of active alarms appears that is organized chronologically with the most recent
at the top of the list, as shown in Figure 6. This example shows the default view, which
appears each time you return to the screen.
Note: A page number appears in the lower right corner of the screen. If a screen contains
more than one page, up/down arrows also appear for viewing the other pages.
Figure 6. Alarms screen (default view)
1. Reset Alarms button
2. Number of alarms
3. Sortable columns—The example is sorted by date/time.
4. Page numbering
5. Alarms categories—The example shows active alarms.
2
4
5
1
3
