Trane Tracer AdaptiView Operation Guide

42 Tracer AdaptiView Display Operations Guide • CTV-SVU01B-EN
Equipment Settings
Feature Settings
Tab l e 9 lists the settings that are available as buttons on the Feature Settings menu
screen, along with their corresponding setting options. The chiller configuration
determines which of the settings appear.
Chilled Water Reset
Tab l e 10 lists the settings that are available as buttons on the Chilled Water Reset menu
screen, along with their corresponding setting options. The chiller configuration
determines which of the settings appear.
Table 9. Feature Settings menu screen: Buttons and available setting options
Feature Available setting options
External Chilled Water Setpoint Enable/Disable
External Current Limit Setpoint Enable/Disable
Ice Building Enable/Disable
Hot Gas Bypass Enable/Disable
Hot Gas Bypass Maximum Timer Enable/Disable
Minimum Capacity Timer Enable/Disable
Security Enable/Disable
Ext Base Loading Setpoint Enable/Disable
Check Oil Filter Diagnostic Enable/Disable
Table 10. Chilled Water Reset menu screen: Buttons and available setting options
Buttons Available setting options
Chilled Water Reset • Disable
• Outdoor Air
•Return
• Constant Return
Return Reset Ratio Valid numerical range appears on screen.
Return Start Reset Valid numerical range appears on screen.
Return Maximum Reset Valid numerical range appears on screen.
Outdoor Reset Ratio Valid numerical range appears on screen.
Outdoor Start Reset Valid numerical range appears on screen.
Outdoor Maximum Reset Valid numerical range appears on screen.
