34 Tracer AdaptiView Display Operations Guide • CTV-SVU01B-EN
Equipment Settings
You can use the Tracer AdaptiView display to monitor and change a variety of equipment
settings.
Viewing the Settings Screen
Tou ch t he Settings button in the main menu area (see “Main Menu Area,” p. 13) to view
the Settings screen. Equipment Settings identifies a column of buttons located on the
screen (see the outlined column in Figure 18). The buttons are:
• Chiller Settings
• Feature Settings
• Chiller Water Reset
• Purge Settings
• Manual Control Settings
Each of these buttons provide access to a screen that contains additional buttons related
to each topic. This section provides detailed information about these screens.
Figure 18. Settings screen with the Equipment Settings column highlighted
