Appendix B: Reports
Log Sheet
Chiller component Report item Unit
Evaporator Evaporator Entering Water Temperature XXX.X °F/°C
Evaporator Leaving Water Temp XXX.X °F/°C
Evaporator Sat Rfgt Temp XXX.X °F/°C
Evaporator Rfgt Pressure XXX.X PSI/kPa
Evaporator Approach Temp XXX.X °F/°C
Evaporator Water Flow Switch Status Flow/No Flow
Condenser Cond Entering Water Temp XXX.X °F/°C
Cond Leaving Water Temp XXX.X °F/°C
Cond Sat Rfgt Temp XXX.X °F/°C
Cond Rfgt Pressure XXX.X PSI/kPa
Cond Approach Temp XXX.X °F/°C
Cond Water Flow Switch Status Flow/No Flow
Compressor Starts XXXX Starts
Running Time XX:XX Hr:Min
Oil Tank Pressure XXX.X PSI/kPa
Oil Pump Discharge Pressure XXX.X PSI/kPa
Oil Differential Pressure XXX.X PSI/kPa
Oil Tank Temperature XXX.X °F/°C
IGV1 Position XXX.X %
IGV1 Position Steps
IGV2 Position XXX.X %
IGV2 Position Steps
